Thread Number: 82143  /  Tag: Vintage Automatic Washers
Tub Light
[Down to Last]

automaticwasher.org's exclusive eBay Watch:
scroll >>> for more items --- [As an eBay Partner, eBay may compensate automaticwasher.org if you make a purchase using any link to eBay on this page]
Post# 1061616   2/27/2020 at 01:12 (1,509 days old) by BootsNslicks14 (The State of Jefferson)

bootsnslicks14's profile picture
Been a while since I've last posted or had free time to get around to the pair of '60s Maytags I was lucky enough to score a few years ago.

Always wanted one with a working tub light.. And the A702 I got came with a tub light, but, if doesn't work.. yet.

I replaced the bulb, made sure the socket and wiring looked good, and it was. I checked for power at the socket and behind the switch and got nothing.. Anyone know what could be wrong? Bad switch?






Post# 1061617 , Reply# 1   2/27/2020 at 01:15 (1,509 days old) by BootsNslicks14 (The State of Jefferson)

bootsnslicks14's profile picture


  Photos...       <              >      Photo 1 of 2         View Full Size
Post# 1061618 , Reply# 2   2/27/2020 at 01:20 (1,509 days old) by BootsNslicks14 (The State of Jefferson)

bootsnslicks14's profile picture
In the second photo, I have the flashlight shining on the back side of the switch. I can post more pics if it would help..

Post# 1061625 , Reply# 3   2/27/2020 at 06:00 (1,509 days old) by Tomturbomatic (Beltsville, MD)

If the machine works with the lid open that could be a sign that the switch is not working and it has to click when you raise the lid to turn the light on, I believe.


Post# 1061633 , Reply# 4   2/27/2020 at 07:57 (1,509 days old) by Yogitunes (New Jersey)

yogitunes's profile picture
first place to start would be to trace with wiring....

Post# 1061636 , Reply# 5   2/27/2020 at 08:22 (1,509 days old) by swestoyz (Cedar Falls, IA)

swestoyz's profile picture
Tom is spot on. I've seen several of these switches go bad. To Martin's point, here's a quick guide on the wiring for the tub light. The neutral side is piggy backed off the timer motor, and the hot side comes from the lid switch.

To test without a meter, pull the lid out and manually push the switch, you should hear an audible, confident click. If it sounds mushy or there is no click at all, it's time for a new switch. With a meter, test across both sides for continuity in both switch positions.

Original PN - 2-1946, Whirlpool replacement is WP206415

Ben


  View Full Size
Post# 1061724 , Reply# 6   2/28/2020 at 02:06 (1,508 days old) by BootsNslicks14 (The State of Jefferson)

bootsnslicks14's profile picture
Thanks to all responses.

@TomTurboMatic : The machine does operate with the lid open and it does NOT make a clicking noise when opening the lid.

@Swestoyz : Yes Tom confirmed my hunch. Thank you for the wiring diagram and the part numbers, that made my life a little easier finding the switch. Found a NOS one on eB@y.

Now I have laundry list (no pun) of other issues with this A702 I have to address, guess I'll start a new thread.

This forum is helpful!
